Suitable for flat, garment, cap, sock, shoe embroidery and other applications.
- Automatic color changing function.
- Automatic thread trimming function.
- Automatic thread locking function.
- Intelligent thread break detection system.
- One-touch power failure reset function.
- One-touch hoop selection function.
- Automatic frame moving function.
- One-touch hoop retraction/advancement function.
- Automatic alarm for design over-limit.
- Front LED lighting.
- Emergency stop button configured.
- Wireless design transmission function.
- Optional visual recognition system.
- Optional design projection function.
| Model | PA Series | PB Series |
| Heads | 1 | 1 |
| Needles | 12/15 | 12/15 |
| Max EmbroideryArea X*Y(mm*mm) | 350*200 | 350*200 |
| Cap embroidery RangeX*Y(mm*mm) | 260*65 | 260*65 |
| Machine Power(W) | 180W | 180W |
| Voltage(V) | 100-230 | 100-230 |
| Dimensions(mm) | 790*900*780 | 790*900*780 |
| Spindle System | Servo Motor | Servo Motor |
| XY Drive System | Open-Loop Stepping Motor | |
| XY Drive Structure | Bottom Support | Suspension |
| Hoop Support | Flat/Cap/Sock/Shoe | |
| Supported Design Formats | DST/DSB,etc | |
| Language Support | Chinese/English/Spanish/Turkish/French/Portuguese/Japanese/Korean/Thai/Italian/German/Indian/Vietnamese, etc | |
