Suitable for flat, garment, cap, sock, shoe embroidery and other applications.
- Automatic thread trimming function.
- Automatic color changing function.
- Automatic thread locking function.
- Intelligent thread break detection system.
- One-touch power failure reset function.
- One-touch hoop selection function.
- Automatic frame moving function.
- Automatic alarm for design over-limit.
- Emergency stop button configured.
- External start/stop button.
- Standard red light positioning.
| Model | PEJ-6 | PEJ-8 | PEJ12 |
| Heads | 6 | 8 | 12 |
| Needles | 12/15 | 12/15 | 12/15 |
| Head Distance(mm) | 400 | 400 | 400 |
| Max EmbroideryArea X*Y(mm*mm) | 400*450 | 400*450 | 400*450 |
| Cap embroidery RangeX*Y(mm*mm) | 260*65 | 260*65 | 260*65 |
| Machine Power(KW) | 1.5 | 1.5 | 1.5 |
| Voltage(V) | 200-230 | 200-230 | 200-230 |
| Dimensions(mm) | 1540*3430*1620 | 1540*4230*1620 | 1540*5830*1620 |
| Spindle System | Servo Motor | Servo Motor | Servo Motor |
| XY Drive System | Servo Motor | Servo Motor | Servo Motor |
| XY Drive Structure | Bottom Support | Bottom Support | Bottom Support |
| Hoop Support | Flat/Garment/Cap/Sock/Shoe | ||
| Device Support | Sequin/Easy-Cording/Easy-Chenille | ||
| Projection System | Optional | ||
| Supported Design Formats | DST/DSB,etc | ||
| Language Support | Chinese/English/Spanish/Turkish/French/Portuguese/Japanese/Korean/Thai/Italian/German/Indian/Vietnamese, etc | ||
