Compact home & commercial embroidery machines are perfect for fashion clothing stores, personalized embroidery online shops, home DIY, school teaching, tourist spot retail stores, and startup businesses, widely used for custom embroidery on finished hats, garments, socks, and more.
- A single machine handles multiple applications: cap embroidery, garment embroidery, shoe embroidery, bag embroidery, sock embroidery and more.
- High-resolution true-color touchscreen with user-friendly touch screen.
- Multi-functional integrated design with diversified models.
- Various specifications of optional accessories available to meet all embroidery application requirements.
- Quiet operation with high speed: maximum 1200rpm for flat embroidery, 1000rpm for cap embroidery.
- Supports multiple language versions.
- Supports networking system, projection effect, visual positioning and wireless transmission functions.
- Large memory capacity: 2 million stitches or 200 patterns.
- Supports multiple pattern formats including DST, DSB, EMB and others.
- Optional additional accessories include: tubular frame, strong magnetic frame, perforation, shoe frame, cap driver, tape frame, automatic fabric clamping, infrared positioning and more.
- Optional additional devices according to model include: sequin, boring, easy-cording, bead, laser cutting and other devices.
| Model |
|
COMMERCIAL MACHINE-PEC1 | COMMERCIAL MACHINE-PEC2 | COMMERCIAL MACHINE-PEC4 |
| Heads |
|
1 | 2 | 4 |
| Needles |
|
12/15 | 12/15 | 12/15 |
| Head Distance(mm) |
|
0 | 500 | 400 |
| Max EmbroideryArea X*Y(mm*mm) |
|
500*400/600*400/800*500 /1200*500/1200*600/1200*700 |
600*500 | 400*400 |
| Machine Power(W) |
|
230W | 300W | 400W |
| XY Drive System |
|
Closed-Loop Stepping Motor | Closed-Loop Stepping Motor | Closed-Loop Stepping Motor |
| XY Drive Structure |
|
Suspension | Suspension | Suspension |
| Device Support | Sequin/Easy-Cording/Laser/Bead/Easy-Chenille | Sequin/Easy-Cording | ||
| Presser Foot System | Standard/ERED Presser Foot/Electronic Presser Foot | |||
| Supported Design Formats | DST/DSB,etc | |||
| Hoop Support | Flat/Garment/Cap/Sock/Shoe | |||
| Language Support | Chinese/English/Spanish/Turkish/French/Portuguese/Japanese/Korean/Thai/Italian/German/Indian/Vietnamese, etc | |||
