Suitable for flat, garment, cap, towel embroidery and other applications
- Independent color change system for towel embroidery
- H-axis with servo system, max speed 950 RPM
- ERED presser foot system
- ERED Electronic Presser Foot System
| Model | PEX Chenille series |
| Heads | 1+1 |
| Needles | Flat Embroidery:9/12/15 Needles Chenille:6 Needles |
| Head Distance(mm) | 500 |
| Max EmbroideryArea X*Y(mm*mm) | 1200*600/1400*600 |
| Cap embroidery RangeX*Y(mm*mm) | 260*65 |
| Machine Power(KW) | 600W |
| Voltage(V) | 200-230 |
| Spindle System | Servo Motor |
| XY Drive System | Closed-loop Stepping Motor |
| XY Drive Structure | Suspension |
| Towel H-axis | Servo Motor |
| Hoop Support | Flat/Garment/Cap/Sock/Shoe |
| Device Support | Sequin/Easy-Cording/Laser/Bead/Easy-Chenille |
| Projection System | Standard/ERED Presser Foot/Electronic Presser Foot |
| Supported Design Formats | DST/DSB,etc |
| Language Support | Chinese/English/Spanish/Turkish/French/Portuguese/Japanese/Korean/Thai/Italian/German/Indian/Vietnamese,etc |
