Widely applied in apparel, footwear, luggage & bag, home textiles and decorative crafts industries. Supports integrated techniques combining embroidery, laser processing and mechanical sequin punching to enhance customized design possibilities.

• Dedicated industrial-grade control system operating at 1000rpm;
• Vibrant color options with up to 12 colors persingle head.
• Diverse shapes selection: Minimum size 0.4mm, optional sizes 0.6/0.8/1.0/1.2/1.5/2.0/3.0/4.0/5.0mm, special shapes include plum blossom/crescent/square/star;
• Exclusive Korean technology and patented modular punch head components with imported wear-resistant needles;
• High-precision feeding: 0.1mm spacing accuracy, 0.05mm sequin overlapping accuracy, prevents flipping/missing;
• Missing piece detection, one-touch threading/feeding, active material pulling with user-friendly scrap collection system.
• Head structure: Balanced head structure reducing vibration; positioning pin installation ensuring accuracy.
• Punch head assembly:
• (1) Modular design for interchangeable size combinations;
• (2) Independent motor-driven sequin feeding with adjustable distance;
• (3) Dual-guide system ensures high concentricity and extended service life;
• Patch embroidery frame:
• (1) High-precision lightweight floating frame ensures consistent needle penetration depth;
• (2) Closed-loop XY control system delivers quiet operation and high accuracy;
• (3)Electrostatic film design: High viscosity and precision. Sticker switching convenience;
• (4) Real-time display of embroidery patterns and frame boundaries with automatic out-of-range alarm function to minimize material waste;
• Additional functions (optional):
• 360° sequin rotation: Punch head achieves full 360° rotation to accommodate diverse pattern requirements;
• Projection system: Projects complete sequin patterns onto the frame with high positioning accuracy;
• Vision inspection: Detects defects (missing/extra/flipped sequins) and enables one-touch rework, boosting efficiency while reducing scrap rate.
