LACE EMBROIDERY MACHINE

Widely used for batch embroidery of crafts including toys, clothing, footwear, headwear, and home furnishings.

  • Optional head spacing: 55/82.5/110/165 mm or hybrid configurations.
  • Optional models: 10/15/20/25-yard or spliced versions.
  • Internally Installed, High Technology
  • High Speed ,High Efficient
Model
  • 55mm
  • 82.5mm
  • 110mm
  • 165mm
  • Application
  • Key Features
  • Specifications

SINSIM brand lace embroidery machine series delivers exceptional performance in mass production across diverse applications including toys, handbags, footwear, hats, children's clothing, sweaters, underwear, bedding, curtains, towels, straw mats, fabrics, home textiles, and denim apparel.

  • Optional head structures: Single-Cam Dual-Drive Guided / Double Crank.
  • High-precision gantry-milled frame structure.
  • Industrial-grade high-performance computerized embroidery control system.
  • Optional high-precision floating embroidery frame or C-frame.
  • Intelligent lubrication system for upper/lower shafts.
  • High-capacity auto-lubricated rotary hook with diamond coating.
  • Servo motor drive, main drive with high-strength imported timing belts.
  • High-precision custom gear drive box.
  • High-performance upper thread clamping structure.
  • High-performance stepper motor static thread trimming system.
  • Machine-specific dual-system configuration: Dual-hook / Dual-color-change / Dual-drive / Dual-spindle / Dual-Y-axis / Dual-X-axis structure.
  • Optional embroidery attachments of different types and specifications based on head spacing.
  • Compatible with automated systems: auto-thread-trimming / auto-bobbin-changing / auto-fabric-clamping / auto-frame-positioning.
Model Needles Heads Head Interval Emb.area Inner Frame Size Machine Size
LB(4+2)270 4+2 270 55 600*1650 15434*1690 17235*4237
LS4116 4 116 82.5 700*950 10227.5*990 11878*2842
LB(4+3)180 4+3 180 82.5 700*1600 15507.5*1640 17325*4142
LB(4+3)240 4+3 240 82.5 700*1520 20457.5*1630 22548*3982
LS4190 4 190 115 700*1600 22475*1640 24525*4137
LS4132 4 132 110 700*1600 15150*1640 17000*4142
LC658 6 58 165 750*950 10195*990 11895*2577
LC690 6 90 165 750*1600 15475*1640 17425*4077
LC6(130+2) 6 130+2 165 900*1600 22225*1640 24275*4077
LC945 9 45 330 900*1600 15460*1640 17560*3977
LC1265 12 65 330 900*1600 22060*1640 24310*3977

Compatible Device Description

Applications

CLOTHING

TOY

BAG & LUGGAGE

OUTDOOR

CAR INTERIOR

SHOE MAKING

HOME FURNISHINGS
